Alsphalt synchronous chip seal truck is used for gravel seal process in road surface, bridge deck waterproof and lower seal layer. The asphalt spraying and stone spreading are carried out synchronously, so that there is sufficient surface contact between asphalt and stone to achieve the maximum cohesion between them. The liquid asphalt and clean and dry crushed stone are evenly distributed on the pavement.
Item No :
SCST001Order(MOQ) :
1 unitPayment :
TT,LCProduct Origin :
Suizhou,Hubei,ChinaColor :
multicolorShipping Port :
Shanghai,Wuhan,HogrosLead Time :
7-15 daysShacman 7m³Alsphalt Tank and 12m³Stone Tank Alsphalt Synchronous Chip Seal Truck
Production description
1. Shacman asphalt synchronous chip seal truck adopts the Shacman engineering chassis with strong bearing capacity.The cab with high top and high configuration is selected to make driving more comfortable;
2. The asphalt pump is JOHNSON pump from Belgium, which has good self-priming performance, large speed range, good sealing performance, and stable flow to ensure the quality of asphalt distribution.
3. Stone distribution and asphalt distribution are controlled by multiple groups of cylinders, and each cylinder can be independently controlled and freely adjusted.
Specification of Shacman 7m³Alsphalt Tank and 12m³Stone Tank Alsphalt Synchronous Chip Seal Truck
|
SPECIFICATION |
||
|
Truck specification |
|
|
|
Product name |
Shacman 7m³Alsphalt Tank and 12m³Stone Tank Alsphalt Synchronous Chip Seal Truck |
|
|
Over dimensions(LXWXH) |
9880X2550X3820mm |
|
|
Chassis specification |
|
|
|
Cabin |
Shacman M3000 |
|
|
Drive type |
6x4 |
|
|
Wheelbase |
4575+1400mm |
|
|
Fuel type of engine |
Diesel |
|
|
Engine |
Model |
WP8.350E61 |
|
Maximum horse power |
350HP |
|
|
Number of cylinders |
10 |
|
|
Emission standard |
Euro III |
|
|
Gearbox |
Type |
FAST,Manual,10 forwards and 2 reverse |
|
Tyres |
Size |
12,00R20 radial tyre |
|
Quantity |
10+1 spare tire |
|
|
Upper body specification |
|
|
|
Spreader width |
4500mm |
|
|
Stone particle size |
3-25mm |
|
|
Stone tank capacity |
12m³ |
|
|
Asphalt tank capacity |
7m³ |
|
|
Tank material |
Q235 high quality carbon steel+stainless tank surface+insulating layer |
|
|
Fiber length |
30mm/60mm/120mm |
|
|
Fiber sprinkle amount |
950l/min |
|
|
Sprinkling medium |
base asphalt, modified asphalt, diluted asphalt, emulsified asphalt |
|
